Dimensiwn terfyn y cynnyrch:
Cydrannau'r dwyn rholio cyfun 4.062:
Mae'r dwyn rholer cyfun 4.062 yn cynnwys canolbwynt, dwyn rheiddiol a rholer echelinol y mae'r llun canlynol yn ei ddangos:
Cymhwyso'r dwyn:
Fforch godi, pentwr cynhwysydd, elevator bwced, peiriant twnelu, offer metelegol, ac ati
Cynhyrchion tebyg eraill sydd ar gael yn SUN AUTOMATION GROUP LIMITED:
|
DYLANWAD CYFEIRIAD
|
Dimensiynau(mm) |
C |
C0 |
Ca |
C0a |
ID y rheiddiol |
PROFFIL |
PLÂT |
||||||||
|
D |
T |
d |
H |
h |
B |
A |
S |
r |
kN |
kN |
kN |
kN |
dwyn |
CYF |
CYF |
|
|
4.053 |
52.5 |
40 |
30 |
33 |
27 |
17 |
2 |
15 |
2 |
24 |
32 |
7 |
7 |
28 |
EC053 |
PL 00 |
|
4.054 |
62 |
42 |
30 |
37.5 |
30.5 |
20 |
2.5 |
20 |
3 |
31 |
35.5 |
11.5 |
11.5 |
38 |
2890 |
PL 0 |
|
4.055 |
70.1 |
48 |
35 |
44 |
36 |
23 |
2.5 |
22 |
4 |
45.5 |
51 |
14 |
13 |
42 |
2867 neu 3018 |
PL 1 |
|
4.056 |
77.7 |
54 |
40 |
48 |
36.5 |
23 |
3 |
24 |
4 |
48 |
56.8 |
18 |
18 |
46 |
2810 |
PL 2 |
|
4.057 |
77.7 |
53 |
40 |
40 |
29 |
23 |
3 |
24 |
4 |
48 |
56.8 |
18 |
18 |
46 |
3019 |
|
|
4.058 |
88.4 |
59 |
45 |
57 |
44 |
30 |
3.5 |
26 |
3 |
68 |
72 |
23 |
23 |
50 |
2811 neu 3020 |
PL 3 |
|
4.059 |
101.2 |
67 |
50 |
46 |
33 |
28 |
3 |
30 |
3 |
73 |
82 |
25 |
27 |
58 |
2912 |
|
|
4.060 |
107.7 |
71 |
55 |
54 |
40 |
31 |
3 |
34 |
5 |
81 |
95 |
31 |
36 |
63 |
3100 |
|
|
4.061 |
107.7 |
71 |
60 |
69 |
55 |
31 |
3 |
34 |
5 |
81 |
95 |
31 |
36 |
63 |
2862 |
PL 4 |
|
4.062 |
123 |
80 |
60 |
72.3 |
56 |
37 |
5 |
40 |
5 |
110 |
132 |
43 |
50 |
71 |
2891 neu 3353 |
PL 4 |
|
4.063 |
149 |
103 |
60 |
78.5 |
58.5 |
45 |
5.5 |
50 |
3 |
151 |
192 |
68 |
71 |
90 |
2757 |
PL 6 |
Dull cludo:
Ein warws a phacio:
